Screw Conveyors

Next > >

Screw Conveyors

<< Previous

Send Inquiry

Product Code : 19

Price And Quantity

Minimum Order Quantity
1
Unit of Measure
Piece/Pieces

Price Range
500000.00 - 15000000.00 INR

Product Description

Screw Conveyors are specially designed for both horizontal or inclined conveying of materials. Widely recommended for efficiency and reliability, these screw conveyors are used in various industrial as well as agricultural activities. These conveyors consists of an outlet and inlet sections, drive assembly and trough sections which are fitted with screw flight. As per the requirements, these conveyors are also manufactured for large turn-key projects also. Besides this, these are most commonly used for the transportation of cereals, malt, seeds and similar products. Manufactured as per specific industry set quality guidelines and delivered with all the essential documents, these conveyors are demanded for their long uninterrupted working hours, high load bearing capacity and competitive prices.

Features & Technical Specifications:

Type	Conveying speed m/sec.	RPM	Capacity filling 0.45(m3/h)	Capacity density 700 kg/m3/h (t/h)
SN-135	0.5 0.3	220 130	12 7	8 5
SN-180	0.5 0.3	165 100	21 13	15 9
SN-230	0.5 0.3	130 75	34 20	24 14
SN-280	0.5 0.3	105 65	49 30	34 21
SN-315	0.5 0.3	100 60	63 38	44 27
SN-400	0.5 0.3	85 50	100 59	70 41
SN-500	0.5 0.3	75 45	159 95	111 67
SN-600	0.5 0.3	65 40	223 137	156 96
SN-800	0.5 0.3	60 35	407 238	285 167
